Recycling

Designed for in-house scrap recycling,
our systems close the loop for sustainable, cost-efficient production.

PECO Series

PECO is the ideal solution for processing all types of scrap plastic, including HDPE, LDPE, PP (Water cooling), LLDPE blends. Films, thick walled parts as well as fibers and textiles can all be processed without the need for pre-size reduction. Sensors in the feed hopper enable the use of multiple feed systems to be run simultaneously. The granulates can then be re-used in the manufacturing process using gravimetric or batch-weight feed systems. Equipped with one-button start automation, pellet length control and auto-shutdown when no material is sensed, the series PECO is perfect for high-efficiency, safe and simple operation.

FEATURES

Material (via the optional feed system) is fed directly into the feed hopper where it is size-reduced by the integral single shaft shredder. The shredded material is then fed continuously into the special designed PECO screw where the material is processed with minimal heat degradation and then pelletized using water cooling.
The granulate can then be re-used in the manufacturing process using gravimetric or batch-weight feed systems.
One button start automation.
Pellet length control.
Auto-shutdown if no material.

SPECIFICATIONS

Model	PECO 60	PECO 80	PECO 100	PECO 120	PECO 150
Applicable Materials	HDPE, LDPE, PP	HDPE, LDPE, PP	HDPE, LDPE, PP	HDPE, LDPE, PP	HDPE, LDPE, PP
Max. Output (kg / hr)	100-130	150-250	300-400	400-600	850-1000
Main Motor (hp)	25	60	125	200	350
Installed Power (kw)	79	124	220	290	530
Running Power (kw)	55	87	154	203	371
Pelletization	Pellet Bead	Pellet Bead	Pellet Bead	Pellet Bead	Pellet Bead
Control System	Touchscreen / one-button start / Auto-shutdown	Touchscreen / one-button start / Auto-shutdown	Touchscreen / one-button start / Auto-shutdown	Touchscreen / one-button start / Auto-shutdown	Touchscreen / one-button start / Auto-shutdown
Cooling	Water Cooling	Water Cooling	Water Cooling	Water Cooling	Water Cooling
