Extrusion

From mono to 7-layer extrusion, Lung Meng’s blown film lines deliver high-output,
customized packaging films for diverse applications.

Mono Layer Blown Film Machine
AB Series

The high performance main motor AC inverter drive of this series is designed for energy saving and minimum maintenance. Accuracy and reliability are enhanced by the nip inverter motor. With the Italian branded gear box that has a high torque and reinforced lubrication system, the machine’s down time is significantly reduced. High output and homogeneity are created through the outstanding screw & barrel.

FEATURES

High performance main motor AC inverter drive is designed for energy saving as well as minimum maintenance
Nip inverter motor is designed for accuracy and reliability
Gear box uses high torque and enforced lubrication system to minimize machine down time
High mixing quality from screw and barrel results in good homogeneity and high output

SPECIFICATIONS

Model	AB90T	AB100T	AB120T	AB150T
Effective Film Width (mm)	2000	2700	3200	4000
Extrusion Output (Max. kg / hr)	HDPE:250 / LDPE:300	HDPE:320 / LDPE:370	HDPE:380 / LDPE:440	HDPE:480 / LDPE:550
Screw Dia. (mm)	ø90	ø100	ø120	ø150
Pinch Roller Width (mm)	2100	2800	3300	4200
