Extrusion

From mono to 7-layer extrusion, Lung Meng’s blown film lines deliver high-output,
customized packaging films for diverse applications.

Mono Layer Blown Film Machine
Regular

Equipped with the high performance AC main motor & inverter, PID temperature controller and user friendly HMI control system, this series LE is the ideal mono layer blown film machine for minimum power consumption, labor cost and space needed. The improved die and air ring ensures higher quality of film.

FEATURES

Supplied with high performance AC main motor & inverter, which is designed for energy saving as well as minimum maintenance.
Minimum power consumption and labor cost.
Equipped with PID temperature controller and user friendly HMI control system, ideal for space saving.
Improved die and air ring design, ensures higher film quality and easier production control.

SPECIFICATIONS

Model	LE30T	AE45T-HD	AE45T-LD	AE55T-HD	AE55T-LD	AE65T-HD	AE65T-LD
Effective Film Width (mm)	350	800	800	1000	1000	1200	1200
Extrusion Output (Max. kg / hr)	20	50	50	70	70	120	120
Screw Dia. (mm)	ø 30	ø 45	ø 45	ø 55	ø 55	ø 65	ø 65
Pinch Roller Width (mm)	400	850	850	1050	1050	1250	1250
